ELECTRICAL SOLUTIONS

Low-Voltage
Products

Proven Low Voltage Products for Power Management

Point Eight Power offers high-quality, third-party-type-tested switchgear, switchboards and control panels for low-voltage applications, including generator control, distribution, cogeneration, peak shaving and outdoor-rated switchgear up to 600V for UL applications.

Arc-Resistant Switchgear Built for
Performance and Compliance

Point Eight Power’s Low-Voltage Metal Enclosed Arc-Resistant Switchgear is third-party tested by KEMA to meet IEEE C37.20.7 for internal arcing faults up to 85kA. Designed for IEEE C37.20.7 Type 2B accessibility, it provides arc resistance on all sides – even with designated LV compartments open.

Per NFPA 70E, it maintains a hazard risk category of zero with breaker doors closed and latched. Configurable to UL 1558 or UL 891, it adapts to various applications and footprint requirements.

Learn More

Built to Withstand High-Shock and Vibration

With increasing seismic activity worldwide, switchgears must withstand earthquakes while maintaining functional requirements. Our low-voltage switchgear is third-party shake table tested to meet ICC-ES AC 156 and IBC standards, using ASCE 7 as the performance benchmark. It endures a Test Response Spectrum of SDS = 1.98g, ground level, 5% damping, and a ZPA of 0.792g.

With 50+ years of expertise in custom switchgear and control panels for Marine and Oil & Gas industries, Point Eight Power offers designs up to 600V UL and 690V IEC, including stainless steel, aluminum, high-shock, and vibration-resistant options. Our low-voltage product line also includes DC switchgear for industrial, military, and transit applications, as well as generator and engine control panels.

Certifications and Accreditations
UL Listings
UL-67MS: Panelboards, Marine Supplement
UL-508: Enclosed Control Panels
UL-845MS: Motor Control Center, Marine Supplement
UL-891
UL-1558



Listings / Standards
UL-508: Industrial Control Panels
UL-891: Dead Front Switchboards
UL-1558: Metal-Enclosed LV Power Circuit Breaker Switchgear
IEEE C37.20.1: Metal-Enclosed Low-Voltage Power Circuit Breaker Switchgear
IEEE C37.20.7: Guide for Testing Metal-Enclosed Switchgear Rated up to 38kV for Internal Arcing Faults

Low-Voltage Products

  • Arc Resistant Switchgear
  • Distribution Switchgear
  • Cogeneration Switchgear
  • Peak Shaving Switchgear
  • Standby Generator Switchgear
  • Outdoor Switchgear
  • Engine/Generator Control Panels
  • Custom Control Panels
  • Motor Control Centers
  • Individual Controllers
  • Transfer Switches
  • Generator Control Switchgear
  • High Resistance Ground Systems
  • Bus Ducts
  • Relay Panels
  • Control Consoles
  • Substations

Low-Voltage Marine Products

  • Generator Control Switchgear
  • Distribution Switchgear
  • Hi Shock Switchgear
  • Engine/Generator Control Panels
  • Miscellaneous Control Panels
  • Individual Controllers
  • Ground Detection Panels
  • Alarm Panels
  • Panelboards
  • Shore Power Panels
  • Motor Control Centers
  • Transfer Switches
  • High Resistance GND System
